Product Details
＋
| Product Features: |
- One ways of HDMI signal input convert to one ways of optical fiber signal output and one ways coaxial signal output
- Digital audio output format support : LPCM2.0/DTS/Dolby-AC3
- The highest support 192 KHz sampling rate
- Used the optical fiber cable loss less the 0.2Db/m, Output distance is up to 30m
- Used the standard coaxial cable output can be up to 10m
- Operating and Connecting:
- The HDMI audio extractor input port through the HDMI cable connected to HDMI source devices
- The HDMI audio extractor output port through the optical fiber cable or coaxial cable connected to the optical fiber signal receiver or coaxial signal receiver (such as AV amplifier and so on)
- Connect DC5.5mm cable to device DC 5V input port. And connect the USB port to standard USB(Type A) power interface
| Product Specifications: |
| Type: | HDMI Converter |
| HDMI Input Audio Format: | LPCM2.0/DTS/Dolby-AC3 |
| Digital Audio Output Format: | LPCM2.0/DTS/Dolby-AC3 |
| Optical Fiber Cable Output Distance: | |
| Coaxial Cable Output Distance: | |
| Max Working Current: | DC 300mA/5V |
| Net Weight: | 68g / 2.4 oz |
| Size: | 50 x 49 x 20mm / 1.97 x 1.93 x 0.79 inch |
| Package Contents: |
- 1 x HDMI Audio Extractor
- 1 x USB to DC 5.5mm Power Cable
- 1 x Operation Manual
